Model

B635A

BC6050

Max. shaping stroke (mm)

350

500

Max. distance between ram bottom surface to worktable (mm)

330

370

Max. longitudinal movement distance (mm)

400

525

Max. vertical movement distance (mm)

270

270

Max. distance between cutter to ram front surface (mm)

550

Max. rotary degree of tool post

±55 º

±60 º

Max. stroke of the toolhead (mm)

110

120

Ram stroke number per minute（times/min）

32、50、80、125、

32,50,80,125

Worktable feed range

Vertical (mm)

0.18, 0.73

0.4-5.0

Longitudinal (mm)

0.21, 0.84

0.08-1.0

Motor

1.5kw

3kw

Package dimension (mm)

1530×930×1370

2000x1250x1400mm

Net / Gross weight (kg)

1000kg/1200kg

1650/1760kg
